Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
MAINTENANCE
Owner’s Guide
75
When you lift the vehicle, put the jacks and jack stands at the areas indicated only.
Tool List Quantity Tool List Quantity
Floor Jack ....................................................................1 Jack Stands.............................................4
Wheel Chock ...............................................................4
Remove payload from vehicle before lifting. No person(s) should be in or on the vehicle while lifting.
How to lift the entire vehicle:
1. Install wheel chocks in front and behind each front wheel.
2. Center the jack under the rear axle tube next to the differential housing.
3. Lift the vehicle enough to place two jack stands under the frame where the
leaf spring mounting brackets are welded to the frame.
4. Lower the jack and test the stability of the vehicle on the two jack stands.
5. Place the jack under the center front just behind the bumper.
6. Lift the vehicle and place two jack stands under the frame where the instru-
ment panel support is attached to the frame.
7. Lower the jack and test the stability of the vehicle on the jack stands.
