Chapter 13
13 - 4
8900 platform hardware and operating specifications
Table 13.3 lists hardware and operating specifications that apply to the 8900
platform.
Item Specification
Dimensions 3.5"H x 17.75"W x 20.75"D (8.89 cm H x 45.09 cm x
52.71 cm D) per unit 2U industry standard rack-mount
chassis
Mounts in a standard 19-inch EIA rack
Weight 45.5 lbs (20.64 kg) with two power supplies, two hard
drives, and bezel installed (per unit)
47.5 lbs (21.55 kg) with front mount rack bracket
installed
50.5 lbs (22.91 kg) with rail kit installed
Processor
Two Quad-Core AMD Opteron
™
processors
Network interface 16x10/100/1000 BASE-TX Copper ports
8x1000BASE-SX SFP Fiber ports
2x10GE SFP+ Fiber ports
1000BASE-SX - 850nm (LC Connector)
1000BASE-LX - 1310nm (LC Connector, optional)
10BaseT, 100BaseT, 1000BaseT Copper SFP (RJ45
Connector, optional)
1x10/100/1000 Ethernet Management port
Hard drive capacity Two 320 GB hard drives
RAM 16 GB
AC power supply Two 850W 90 - 125 VAC(+/- 10%) or 200 - 240
VAC(+/- 10%) AUTO Switching
Two NEMA 5-15P power cords
DC power supply Two 850W DC, 44 to 75 VDC input
Typical power draw
(dual power supplies;
50% load; temp 25° C)
110VAC input: 397W
208VAC input: 409W
Maximum power draw 535W
Typical heat generated 1536 BTU/hour
1604 BTU/hour
Table 13.3 8900 platform hardware and operating specifications
