Using Additional 6900/8900 Platform Functionality
Platform Guide: 6900 and 8900 4 - 7
Network interface LED behavior
The appearance and behavior of each network interface LED indicate
network traffic activity, interface speed, and interface duplexity. The
network interface speed LED behavior is defined in Table 4.6.
The network interface LEDs blink at their respective duplex colors to
correspond with traffic activity. The network interface status LED behavior
is defined in Table 4.7.
SFP port LED behavior
The appearance and behavior of each small form-factor pluggable (SFP)
port LED indicate network traffic activity, interface speed, and interface
duplexity. The SFP port speed LED behavior is defined in Table 4.8.
Interface Speed LED Appearance
No Link The LED is not lit and does not display any color.
10 The LED blinks yellow.
100 The LED is lit yellow.
1000 The LED is lit green.
Table 4.6 Network interface speed LED behavior
Interface Status LED Appearance
Idle The LED is not lit and does not display any color.
Full duplex The LED blinks green.
Half duplex The LED blinks yellow.
Table 4.7 Network interface status LED behavior
Interface Speed LED Appearance
No Link The LED is not lit and does not display any color.
10 The LED blinks yellow.
100 The LED is lit yellow.
1000 The LED is lit green.
Table 4.8 SFP port speed LED behavior
