FAAC E024S User Manual

E024S 7 732642 - Rev. F
3 TECHNICAL SPECIFICATIONS
Power supply voltage *
230V~(+6%-10%)-50Hz
or
115V~(+6%-10%)-60Hz
Absorbed power 4W
Motor max. load 150Wx2
Accessories max. current
(+24V=)
250mA
BUS Accessories max.current 400mA
Operating ambient tempera-
ture
-20°C...+55°C
Fuses *
F1=self-resetting;
F2 = T2A-250V~ or T4A-
120V~
Function logics
A,E,AP,EP,A1,B,C
Work time (time-out) 5minutes(fixed)
Pause time
Variesaccordingtolearning
(max.10min.)
Terminal board inputs
OpenA,OpenB,Stop,BUS
(I/O)
Connector inputs
Powersupply,battery
moduleXF433orXF868
Terminal board outputs
Motors,flashinglamp,power
supplytoaccessories,elec-
triclock,servicelightcontact
(90secfixed)
Programmable functions Speed(High-Low)
Learning functions
Pausetime,
leafclosingdelay
Integrated radio channels
type
DS,SLH(max250channels)
LC-RC(max250channels)
J1 POWERSUPPLYconnector
J2 SERVICELIGHTcommandterminal-board
J3 FLASHINGLAMPterminal-board
J4 ELECTRICLOCKterminal-board
J5 COMMANDSterminal-board
J7 MOTOR1terminal-board
J8 MOTOR2terminal-board
J9 RapidconnectionforXFMODULE
J10 BUSterminal-board
J11 BATTERYconnector
SW1 SETUPpush-button
SW2 SPEEDpush-button
SW3 LOGICpush-button
DS1 ProgrammingDip-switch
F1 Accessoriesprotectivefuse
F2 Fusesprotectingtransformersandmotors
LED SignallingLEDs
3.1 DESCRIPTION OF COMPONENTS
Terminal and/or
terminal-board
Description Device connected
1
J5
+24V=
Powersupplyfor
accessories
2 GND Negative
3 STOP
DevicewithNC
contactwhich
causesthe
automatedsystem
toshutdown
4 OPENB
DevicewithN.O
contact
5 OPENA
J10
REDterminal
BUS
Safetydeviceswith
BUStechnology
J2
GREYterminal
SERVICE LIGHT
(onfor90sec.
following
movement)
ServiceLightcontrol
output(connecta
relaycoilat24V=
/100mAmax)
J3
ORANGEterminal
LAMP
Flashinglamp
24V= / 15W
J4
BLUEterminal
LOCK
Electriclock12V~
or24V=(tobe
installedonleaf1)
J7 MOT1 Motor1(leaf1)
J8 MOT2 Motor2(leaf2)
3.2 DESCRIPTION OF TERMINAL-BOARDS
5 PROGRAMMING THE SPEED
ThefunctionSPEEDcanbeadjustedatanytimebypressing
push-buttonSW2.
TheselectedspeedisthendisplayedonLEDLD8:
 LEDon =HIGHspeed
 LEDoff =LOWspeed
Leaf 1 means the leaf which opens first during
the opening operation.
The service light control is active during the
entire gate opening or closing movement and
for the successive 90 seconds.
*Thepowersupplyandthefusearerelatedtothepurchased
version. Theself-resettingfuseF1stopsthepowersupplytothe
accessoriesbyopeningacircuitifacurrentover500mAis
detected.Itautomaticallyresetsafter5seconds.
3.3 ANTI-CRUSHING FUNCTION
Theelectronicanti-crushingfunctionisobtainedbycontrolling
the current consumption or the encoder of the motors
connectedtotheE024Sunit.
Ifthegatedetectsanobstacleduringtheopeningorclosing
movement,theanti-crushingfunctionactivatesandreverses
thesenseofdirectionoftheoperator,thusincreasingthesafety
degreeoftheautomatedsystem.
4 PROGRAMMING THE LOGIC
RepeatedlypresstheSW3LOGICpush-buttontoselectoneof
the7programminglogicsavailable.
TheselectedlogicissignaledbytheLD7LED:thenumberof
flashingscorrespondstothenumberoftheselectedlogic.
See paragraph 6.3.3.
ENGLISH

FAAC E024S Specifications

General

Motor Output Voltage	24V DC
Operating Temperature	-20°C to +55°C
Housing	ABS
Power Supply	230 Vac ± 10% 50/60 Hz
Outputs	2
