FAAC E024S User Manual

E024S 8 732642 - Rev. F
6 START-UP
6.1 LEDS CHECK
Checkthestatusoftheinputs,fromtheLEDsontheboard(Tab.1).
Tab.1:inputLEDstatus
(theconditionofclosedautomation instandbyisprovidedin
bold)
LED STATUSES
LED ACTIVE CONTROL NOT ACTIVE CONTROL
STOP Off On
OPENA On Off
OPENB On Off
BUS Seeparagraph7.2
6.2 PROGRAMMING THE DIP-SWITCHES
ThesettingsoftheDS1dip-switchforprogrammingtheforce
andthetypeofmotorareshowninthefollowingtable.
Tab. 2 - DS programming
(default settings in bold)
Before performing the Setup, select the op-
erator connected to the E024S unit with the
DS1(DS3-DS4) DIP switches.
6.3.1 AUTOMATIC SETUP
ToentertheAutomaticsetup,presstheSETUPpush-buttonuntil
thetwoLD4andLD5LEDsarepermanentlylit.Thenrelease
theSETUPpush-button.
DuringtheSetupphasebothLEDsflash.
Theleavesstarttoopenoneatatime,fromanyposition,
tilltheydetecttheopeninglimitstop.Next,theleavesstart
toclose,oneatatime,tilltheydetecttheclosinglimitstop.
Then,theleavesstartagaintomoveautomaticallyoneata
timefromtheclosedposition.
1. Whentheleavesdetecttheopeninglimitstop,theystopin
theopenpositionandtheset-upiscompleted.
IftheSETUPprocedureisperformedcorrectly,theLD4and
LD5LEDsturnoffattheend.Otherwisetheprocedureends
byaskinganewSETUPwithflashingLEDs.
With the AUTOMATIC SETUP, the deceleration
spaces, the leaf closing delays and the pause
time (30 s, with logic A) are automatically
preset during setup.
6.3.2 MANUAL SETUP
ToentertheManualsetup,presstheSETUPpush-buttonuntil
bothLD4,presstheSETUPpush-buttonuntilthetwoLD4andLD5
LEDsarepermanentlylit.Keepitpresseduntiltheautomated
systemstartsmovingautomatically.
DuringtheSetupphasebothLEDsflash.
Theleavesstarttoopenoneatatime,fromanypositiontillthey
detecttheopeninglimitstop.Nexttheleavesstarttocloseone
atatimetilltheydetecttheclosinglimitstop.
Thentheleavesstartagaintomoveautomaticallyoneata
timefromtheclosedposition.
1.Openimpulse--->leaf1deceleratedopeningandstartof
thesearchforleaf1openinglimitstop
-ifthelimitstopisdetected,itissetasstoppointforleaf1
andleaf2startstoopen.
(*)ifanopencommandisdetected,itissetasopening
stoppointforleaf1andleaf2startstoopen.
2.Openimpulse--->leaf2deceleratedopeningandstart
ofthesearchforleaf2openinglimitstop.
-ifthelimitstopisdetected,itissetasopeningstoppoint
forleaf2.
(*)ifanopencommandisdetected,itissetasopeningstop
pointforleaf2.
DS4 DS3 DS2 DS1 Description
OFF OFF MOTOR 391
ON OFF MOTOR 418
OFF ON MOTOR 412-413-415-390-770
ON ON HYDRAULICMOTOR(*)
S450H/S700H/S800H/S800H ENC
OFF OFF LOW FORCE
ON OFF MEDIUM - LOW FORCE
OFF ON MEDIUM - HIGH FORCE
ON ON HIGH FORCE
6.3 TIME LEARNING – SETUP
Before any manoeuvre is executed, a SETUP cycle
must first be run.
If the motor type is changed with the DS3 and
DS4 dip-switches after the SETUP, a new SETUP is
requested with flashing LD4 and LD5 LEDs.
If, after the start of the SETUP procedure, the
leaves close instead of open, reverse the motor
power cables
(*) with the DS3-DS4 selection on ON the opera-
tor connected to the encoder is automatically
recognized during the set-up phase
Important:
The dip-switch arrangement on the E024S board
for 391 is overturned.
WhentheboardispoweredupandaSETUPcyclehas
neverbeenexecuted,LEDsLD4andLD5begintoflash
slowlytosignalthataSETUPcyclemustbeexecuted.
TherearetwopossibletypesofSETUP:
-AUTOMATICSETUP
-MANUALSETUP
(*) During SETUP, to set the stop point, the OPEN
command must ONLY be used with SAFECODER
ENGLISH

FAAC E024S Specifications

General

Motor Output Voltage	24V DC
Operating Temperature	-20°C to +55°C
Housing	ABS
Power Supply	230 Vac ± 10% 50/60 Hz
Outputs	2
