MOTOR BELT TENSION ADJUSTMENT
Wheneverthecuttermakesanunusualnoiseafteracertainperiodoftime,
whichisduetosettlingofthebelt(30),itmaybenecessarytoadjusttensioning.
Operateasfollows:
☞
Do not over-tighten the belt.
In the rotation, the engine could force and the
belt may be damaged.
• Disconnecttheplugfromthesocket.
• Remove the pot (5) from the body of the appliance (1) as described
previously;
• Liftthecutter.
☞
Make sure that the cutter is stable and can not
inadvertently fall.
• For“C3”modelonly(Fig.16):
 -Unscrewall4feet(2)andthescrew(v)underthebase;removethecover
(2b).
 -Loosenthenut(13)andthescrew(10),adjustthebelttensioner(12).
 -Whentheoperationhasbeencompleted,tightenthenut(13)andthescrew
(10).
• For“C5”and“C8”modelsonly(Fig.17):
 -Unscrewall4feet(2)andthescrew(v)underthebase;removethecover
(2b).
 -Loosenthescrews(13),interactwiththetwonuts(15)totensionthebelt.
 -Whentheoperationhasbeencompleted,tightenthescrew(13).
Only for personnel authorized by the manufacturer
