ELECTRICAL AND MECHANICAL SAFETY DEVICES
Thefollowingmechanicalsafetydevicesareused:
• transparentplasticprotectivecover(6)suitableforcontactwithfoodstuffs.
• start-upwithstart/stopbutton(X),whichrequiresintentionalre-startingoftheappliance
intheeventofpowerfailure;
• magnetic micro-switch(12)on thetransparentcover (6),whichdoesnot allowthe
appliancetobestartedwhenthecoverisopen;
• micro-switch(10)locatedunderneaththepot,whichdoesnotallowtheapplianceto
bestartedbeforethepothasbeenpositioned;
• micro-switch(11),whichdoesnotallowtheappliancetobestartedifthepotisnot
properlypositionedontheappliancebody(thepin(P)onthepotmustbepositioned
initsseat);
• appliancepoweronluminousindicatorlight(15).
