TOUCH SCREEN SYMBOLS (OPTIONAL)
3
#1 NAME
SUDSSUDS
Setup Hour Meters Zone Lock
Locked Unlocked
Forward Transport Motor
Working Active Inactive
Reverse Transport Motor
Working Active Inactive
Solution Flow
Working Active Inactive
Vacuum Motor
Working Active Inactive
Solution Setting
#0 #1 #2 #3 #4
Down Pressure Setting
#1 #2 #3 #4
Mode Selection
Transport Only Single Scrub Double Scrub Vacuum Only
Scrub Deck Motor(s)
Working Active Inactive
Suds
250:1 Dilution 125:1 Dilution Inactive
