Factory Cat Pilot - Touch Screen Error Codes

FC-RIDERS-V2-OP-EN v22.235 - 43 -
Error Internal Label Code Type Description Action Remedy
HARD_FAULT
0
Flag used to dene a show-stop-
per failure requiring a power
cycle
SOFT_FAULT
1
Flag used to dene an error that
may disable a device but keep the
rest of the machine operational
NO_ERROR
0
Used internally
Bad Personality BAD_PERSONALITY
10
hard/soft Incompatable options pro-
grammed or a checksum failure
The machine is disabled or
continues operating with
factory default parameters
Check programming
options and/or reprogram
EEPROM
Initial throttle
fault
INITIAL_THROTTLE_FAULT
11
soft Throttle is engaged at power up
preventing a successful return to
idle state
Machine remains in a
pre-idle condition until the
active throttle condition
goes away
Take your foot o the gas
SHORT_CIRCUIT
12
hard
Memory fault EEPROM_READ_ERROR
13
hard/soft An error was detected during an
EEPROM read access
The machine is disabled or
continues operating with
factory default parameters
Cycle keyswitch. If
problem persists change
control board
Dead battery LOW_BATTERY_PROTECT
14
hard The battery voltage has dropped
below NN.n Volts
The machine is disabled
Charge or replace batteries
Low battery
charge
LOW_BATTERY_CHARGE
15
soft The battery voltage has dropped
below NN.n Volts and all but
the transport motor have been
disabled
All but the transport motor
are disabled is disabled
Charge battery
Overheat CPU THERMAL_CUTBACK_MCU 16 hard The microcontroller hardware has
had an over temperature failure
The controller is switched
o
Keyswitch o, wait ten
minutes, keyswitch on. If
problem persists change
control board
PRECHARGE_FAILURE_TRA 17
Transport idle
current fault
TRACT_LEFT_NULL_ERROR 18 hard An abnormally high idle current
has been detected in the trans-
port motor (operational motor)
The machine is disabled
Brush idle
current fault
BRUSH_NULL_ERROR 19 soft An abnormally high idle current
has been detected in the brush
motor (operational motor)
Brush, deck actuator and
water/suds are disabled
Vacuum idle
current fault
VACUUM_NULL_ERROR 20 soft An abnormally high idle current
has been detected in the vacuum
motor (operational motor)
Vacuum motor is disabled
Squeegee idle
current fault
SQUEEGEE_NULL_ERROR 21 soft An abnormally high idle current
has been detected in the squee-
gee motor (operational motor)
Squeegee motor is disabled
BRU_ADJ_OUT_OF_RANGE 22 soft
Transport motor
relay not open
SOLENOID_WELDED_TRA 23 hard The main traction relay was
detected closed during power on
The machine is disabled Keyswitch o, wait ten
seconds, keyswitch on. If
problem persists change
control board
Transport motor
relay not closed
SOLENOID_DIDNT_CLOSE_TRA 24 hard The main traction relay was de-
tected open after being energized
during power on
The machine is disabled
Throttle fault THROTTLE_FAULT 25 hard An illegal voltage has been read
from the throttle feedback circuit
The machine is disabled Check throttle action and
voltages
TOUCH SCREEN ERROR CODES
