SERVICE CABINET
18
19 20 21 22 23
18. VACUUM
DISCHARGE:
Water passed through the
Vacuum Motor will be visible
in the reservoir and excess
will flow from the blue hose.
Indicates service required.
19. VAC BOX UNLOADER:
Unloader valve for the Yellow
Vac Box. Water present in the
Yellow Vac Box will drain when
vacuum is off.
20. SOLUTION FILTER:
Standard Solution Feed Filter
for scrubdeck.
21. SUDS DRAIN:
Drain detergent from Suds
reservoir.
22. ZERO3 FILTER:
Optional ZerO3 (O3+) Ozone
System Solution Filter.
23. BATTERY DRAIN:
Drain any fluid from Poly
Battery Box.
