SERVICE MANUAL
ADVANCE OVENS
04/02/2020 142
o Chimney motor (Ms/Mb).
o Main supply relay (RG).
o Fan (VE).
o Oven lighting (LZ).
o Drainage pump (VAC).
o Wash pump (Mba).
o Drainage motor (Mc/Ma).
o Water inlet solenoid valve (VDV).
o Steam heating (CV1).
o Steam heating (CV2).
• Warning bell (TA).
All outputs are in by default in OFF mode.
17.17. ERRORS
When an error occurs:
• The bell rings intermittently.
• A flashing message is shown on the upper text of the display.
• If the START/STOP button is pressed or the door is opened, the error message continues to be displayed
but the bell stops ringing.
• To reset the error, switch off the oven.
• When the fault causing the error is removed, the outputs return to normal operation.
A list is provided below of possible errors that may arise in the oven:
“E1 SENSOR TC”
DESCRIPTION:
Camera probe broken. TC out of range [-5 ÷ 330 ºC]
CONSEQUENCE:
The oven is completely disabled.
“E2 SENSOR TN”
DESCRIPTION:
Core probe broken. TN out of range [-10 ÷ 400 ºC]
CONSEQUENCE:
The Spike and Delta functions are disabled
“E3 SENSOR TV” (Only electric ovens)
DESCRIPTION:
Steam probe broken. TV out of range [-5 ÷ 330 ºC]
CONSEQUENCE:
It is only possible to operate in Convection mode, omitting water condensation.
“E4 SENSOR TG”
DESCRIPTION:
Broken generator probe. TG out of range [-5 ÷ 330 ºC]
CONSEQUENCE:
It is only possible to operate in Convection mode.
“E5 WATER LEVEL”
DESCRIPTION
Detects water at maximum level, but does not detect it at minimum level for 3 seconds.
CONSEQUENCE
