15. USE OF CONCEPT ACE & ACG OVENS
15.1. ACE ELECTRIC OVEN CONTROL PANEL (until 01/01/2016)
1. Oven ON switch
2. Oven OFF switch
3. Convection/Mixed/Regeneration/Steam
operating mode Selector/Button
4. Convection mode display
5. Mixed mode display
6. Regeneration mode display
7. Steam mode display
8. Chamber true temperature
9. Temperature setting, chamber
10. Temperature selector encoder
11. Remaining cooking time
12. Cooking time set value
13. Time selector encoder
14. Power/Speed Selector/Button
15. Maximum power/Maximum speed display
16. Minimum power/Minimum speed display
17. Minimum Power/Minimum power display
18. Time/Spike/Delta function
Display/Selector/Button
19. Button / Cool Down Display
20. Humidifier button
21. START/STOP button
1
5
6
3
9
2
7
8
4
10
11
12
21
17
16
15
14
13
20
19
18
