Fagor BCS3D - Page 12

12|52 - BCS3D EtherCAT Beta EtherCAT Servo 3 Drive series | Ref.2403
Installation Manual
Medium inertia 1.00 kW feed axis motors
Medium inertia 1.30 kW feed axis motors
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 200 Vac
FBM3J-10ALA122 BCS3D-10AEA-FS02
FAGOR axis motor, 200 Vac, 1.00 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
waterproof plug type.
FBM3J-10ALA222 BCS3D-10AEA-FS02
FAGOR axis motor, 200 Vac, 1.00 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
waterproof plug type.
FBM3J-10ALA142 BCS3D-10AEA-FS02
FAGOR axis motor, 200 Vac, 1.00 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and waterproof plug type.
FBM3J-10ALA242 BCS3D-10AEA-FS02
FAGOR axis motor, 200 Vac, 1.00 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and waterproof plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3J-10ALA
 22 MPC-FBM3J-N8718- EEC-FBM3J-A1724- 03, 05, 08, 10, 15, 20
FBM3J-10ALA
 42 MPC-FBM3J-B8718-
EEC-FBM3J-A1724-
03, 05, 08, 10, 15, 20
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 200 Vac
FBM3G-13ALA124 BCS3D-15AEA-FS02
FAGOR axis motor, 200 Vac, 1.30 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
aviation plug type.
FBM3G-13ALA224 BCS3D-15AEA-FS02
FAGOR axis motor, 200 Vac, 1.30 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
aviation plug type.
FBM3G-13ALA144 BCS3D-15AEA-FS02
FAGOR axis motor, 200 Vac, 1.30 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and aviation plug type.
FBM3G-13ALA244 BCS3D-15AEA-FS02
FAGOR axis motor, 200 Vac, 1.30 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and aviation plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3G-13ALA
 24 MPC-FBM3G-N9314- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
FBM3G-13ALA
 44 MPC-FBM3G-B9314- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
