Ref.2403 | Beta EtherCAT Servo 3 Drive series BCS3D EtherCAT - 13|52
Medium inertia 1.80 kW feed axis motors
Medium inertia 0.85 kW feed axis motors
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 200 Vac
FBM3G-18ALA124 BCS3D-20AEA-FS02
FAGOR axis motor, 200 Vac, 1.80 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
aviation plug type.
FBM3G-18ALA224 BCS3D-20AEA-FS02
FAGOR axis motor, 200 Vac, 1.80 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
aviation plug type.
FBM3G-18ALA144 BCS3D-20AEA-FS02
FAGOR axis motor, 200 Vac, 1.80 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and aviation plug type.
FBM3G-18ALA244 BCS3D-20AEA-FS02
FAGOR axis motor, 200 Vac, 1.80 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and aviation plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3G-18ALA
 24 MPC-FBM3G-N9314- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
FBM3G-18ALA
 44 MPC-FBM3G-B9314-
EEC-FBM3G-A1924-
03, 05, 08, 10, 15, 20
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 400 Vac
FBM3G-09DLA124 BCS3D-10DEA-FS02
FAGOR axis motor, 400 Vac, 0.85 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
aviation plug type.
FBM3G-09DLA224 BCS3D-10DEA-FS02
FAGOR axis motor, 400 Vac, 0.85 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
aviation plug type.
FBM3G-09DLA144 BCS3D-10DEA-FS02
FAGOR axis motor, 400 Vac, 0.85 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and aviation plug type.
FBM3G-09DLA244 BCS3D-10DEA-FS02
FAGOR axis motor, 400 Vac, 0.85 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and aviation plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3G-O9DLA
 24 MPC-FBM3G-N9314- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
FBM3G-09DLA
 44 MPC-FBM3G-B9314-
EEC-FBM3G-A1924-
03, 05, 08, 10, 15, 20
