When the operation period in regeneration mode is continuous. add the following items to
the above calculation procedure in order to find the required capacity (W) for the
regeneration resistor.

Energy (J) for continuous regeneration mode operation period:
Eg = (2/60) Nmg x Tg x tg
Here:
Tg. Servomotors generated torque (N·m) in continuous regeneration mode operation period.
Nmg. Servomotors rotation speed (rev/min) for same operation period as above.
tg. Same operation period (s) as above.
 Energy (J) consumed by regenerative resistor:
Ek = Es - (El + Em + Ec) + Eg
 Required capacity (W) of regenerative resistor:
Wk = Ek / (0.2 x T)
Servo amplifier capacitors capacity information
Resistance among motor windings information
5
Find the energy
consumed by the
regenerative resistor
Ek
Ek in J
Ek = Es - (El+Em+Ec)
6
Calculate the required
regenerative resistor
capacity
Wk
Wk
in W
Ek in J
T in s
Wk = Ek / (0.2 x T)
T
: regenerative cycles
SERVO AMPLIFIER CAPACITOR CAPACITY
( µF)
SERVO AMPLIFIER CAPACITOR CAPACITY
( µF)
BCS3D-02AEA-FS02
660
BCS3D-10DEA-FS02
280
BCS3D-04AEA-FS02
660
BCS3D-15DEA-FS02
280
BCS3D-08AEA-FS02
1 120
BCS3D-20DEA-FS02
500
BCS3D-10AEA-FS02
1 360
BCS3D-30DEA-FS02
500
BCS3D-15AEA-FS02
1 760
BCS3D-50DEA-FS02
820
BCS3D-20AEA-FS02
1 760
BCS3D-75DEA-FS02
1 000
FBM3J
SERVOMOTOR
PHASE / LINE
RESISTANCE ( )
FBM3G
SERVOMOTOR
PHASE / LINE
RESISTANCE ( )
FBM3J-02ALA
 2
4.180 / 8.360
FBM3J-04ALA  2
1.842 / 3.684
FBM3J-08ALA  2
0.574 / 1.148
FBM3G-09ALA  4
0.3815 / 0.7630
FBM3J-10ALA  2
0.353 / 0.706
FBM3G-13ALA  4
0.2435 / 0.4870
FBM3G-18ALA  4
0.1565 / 0.3130
FBM3G-09DLA  4
1.5205 / 3.0410
FBM3G-13DLA  4
0.9680 / 1.9360
FBM3G-18DLA  4
0.5855 / 1.1710
FBM3G-29DLA  4
0.2250 / 0.4500
FBM3G-44DLA  4
0.1680 / 0.3360
FBM3G-55DLA  4
0.1030 / 0.2060
FBM3G-75DLA  4
0.0800 / 0.1600
