Selecting peripheral devices
FEED AXIS COMPACT
SINGLE-DRIVE MODEL
BCS3D-XXEA-FS02
LINE
VOLTAGE
( Vac )
INTERNAL
REGENERATIVE
RESISTOR
MIN. ADMISSIBLE
RESISTANCE
( )
MIN. RATED CURRENT
for CIRCUIT BREAKER
( A )
BCS3D-02AEA-FS02
single-phase
200 ... 240
x 45 4
BCS3D-04AEA-FS02
single-phase
200 ... 240
x 45 4
BCS3D-08AEA-FS02
single-phase
200 ... 240
50  / 60 W
25 6
BCS3D-10AEA-FS02
single-phase
200 ... 240
50  / 60 W
25 6
BCS3D-15AEA-FS02
single-phase
200 ... 240
40  / 80 W
25 16
BCS3D-20AEA-FS02
single-phase
200 ... 240
40  / 80 W
25 16
BCS3D-10DEA-FS02
three-phase
380 ... 440
100  / 80 W 65 4 (3-ph)
BCS3D-15DEA-FS02
three-phase
380 ... 440
100  / 80 W 65 6 (3-ph)
BCS3D-20DEA-FS02
three-phase
380 ... 440
50  / 80 W 40 10 (3-ph)
BCS3D-30DEA-FS02
three-phase
380 ... 440
50  / 80 W 40 16 (3-ph)
BCS3D-50DEA-FS02
three-phase
380 ... 440
35  / 80 W 20 20 (3-ph)
BCS3D-75DEA-FS02
three-phase
380 ... 440
35  / 80 W 20 25 (3-ph)
SPINDLE COMPACT
SINGLE-DRIVE MODEL
QC-CD-X-FX-X
LINE
VOLTAGE
( Vac )
RMS
POWER
( W )
MIN. ADMISSIBLE
RESISTANCE
( )
EXTERNAL BRAKING
RESISTOR
MODEL
QC-CD-021-F
 -  400 650 24 ER+TH-24/750
QC-CD-030-F
 -  400 950 24 ER+TH-24/1100
QC-CD-040-F
 - 
400
2 000
18
ER+TH-18/2200
2 000
ER+TH-18/1000+FAN
3 000
ER+TH-18/1500+FAN
4 000
ER+TH-18/2000+FAN
QC-CD-055-F  -  400 4 000 18 ER+TH-18/2000+FAN
