Fagor DDS Series User Manual

Auxiliary modules
4.
AUXILIARY MODULES
Auxiliary power supply. APS-24
200
Ref.1912
DDS
HARDWARE
· 194 ·
Connectors
The APS-24 auxiliary power supply has the following connectors:
F. H4/10
APS-24, auxiliary power supply. Connectors.
X1. Input connector to feed the auxiliary power supply from mains. It admits
a line voltage between 400 V AC and 460 V AC.
X2. Output connector of the auxiliary power supply offering 24 V DC.
X3. Output connector of the auxiliary power supply offering 24 V DC.
X4. Output connector of the auxiliary power supply offering 24 V DC.
1
2
3
+24Vdc.
0V.
CHASSIS
+24Vdc.
0V.
CHASSIS
+24Vdc.
0V.
CHASSIS
1
2
3
1
2
3
1
2
3
L1
L2
CHASSIS
Note. The maximum current of 10 A is the total current that the power supply can
provide as the sum of all the currents that may be supplied through the three 24 V
DC connectors; in other words, it can provide a maximum total power of 240 W (all
of them together), but not through each one.
Imax total = 10 A
Pmax total = 240 W
