Installation
8.
Ref.1912
· 297 ·
DDS
HARDWARE
Values that may be assigned to the transmission speed
The possible values, supported by the hardware, that may be selected to set
the transmission speed are:
See the values that will be assigned to their associated parameter QP11 in
chapter 13 of the “man_dds_soft.pdf” manual.
T. H8/4 Transmission speed with SERCOS interface. Display at the drive.
Value Speed Shown on the display
QP11= 0* 4 MBd
QP11= 1
* 2 MBd
QP11 = 2 2 MBd
QP11 = 4 4 MBd
QP11 = 8 8 MBd
QP11 = 16 16 MBd
*
to be compatible with previous versions of the SERCOS board.
