10
1.3 SYSTEM OVERVIEW
The Merlin is made up of four interconnecting components, the Merlin Console and
external power supply, a Flat Screen Display Monitor and a Engine rack mounted unit which
contains all the electronic circuitry, disk drives and audio I/O necessary to run the system.
Console Power Supply Unit
Merlin Console & Flat Screen Monitor
Engine
