19
SECTION 3 - MERLIN CONSOLE PHYSICAL INSTALLATION
3.1 INTRODUCTION
The Merlin Console provides a control surface to allow the engineer to work quickly
and efficiently. The Console has a number of user definable macros and keystrokes. For
more information regarding the operational use of the console please refer to the Merlin
User manual.
3.2 MECHANICAL INSTALLATION
The Merlin Console should be sat on a level horizontal surface.
Merlin Console
Mouse Port
Merlin Back Panel
Console Controller Port
Power Switch
Power Supply Port
Keyboard
