A1.1 ANALOG AUDIO I/O SPECIFICATIONS
Connector 50 way 3 Row D Female
Input Balanced
Input Level +24dbu max
Input Sensitivity +4dbu nominal (adjustable)
Input Impedence > 10k Ohms
Output Electronic balanced differential
Output Level +24dbu max at 0dBFS, nominal +4dbu
Output Impedence < 55 Ohms
Output Load >600 Ohms
A1.2 DIGITAL AUDIO I/O SPECIFICATIONS
Connector 50 way 3 row D Female
Channels 16 stereo pairs per I/O Module
Sample Rates 32KHz, 44.1 KHz, 48Khz, 88.2KHz, 96 KHz,
0.1% run up and run down
Input Type > 200mV differential
Output level >4.3V TTL
