1.1.1 24 Track Digital 24 Digital I/Os 1 QDC Card
Analog Inputs Analog Outputs Digital Inputs Digital Outputs
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
D In 1 - 2 1 2 173350 D Out 1 - 2 1 2 132946
D In 3 - 4 163249 D Out 3 - 4 122845
D In 5 - 6 153148 D Out 5 - 6 112744
D In 7 - 8 143047 D Out 7 - 8 102643
D In 9 - 10 1 2 9 25 42 D Out 9 - 10 1 2 5 21 38
D In 11 - 12 8 24 41 D Out 11 - 12 4 20 37
D In 13 - 14 7 23 40 D Out 13 - 14 3 19 36
D In 15 - 16 6 22 39 D Out 15 - 16 2 18 35
D In 17 - 18 1 1 9 25 42 D Out 17 - 18 1 1 5 21 38
D In 19 - 20 8 24 41 D Out 19 - 20 4 20 37
D In 21 - 22 7 23 40 D Out 21 - 22 3 19 36
D In 23 - 24 6 22 39 D Out 23 - 24 2 18 35
To Next Page
