41
2.1.2 32 Track Mixed I/O32 Digital I/O – 16 Analog Inputs 1 QDC Card
Analog Inputs Analog Outputs Digital Inputs Digital Outputs
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
A In 1 1 1 17 33 50 D In 1 - 2 1 2 17 33 50 D Out 1 - 2 1 2 13 29 46
A In 2 16 32 49 D In 3 - 4 16 32 49 D Out 3 - 4 12 28 45
A In 3 15 31 48 D In 5 - 6 15 31 48 D Out 5 - 6 11 27 44
A In 4 14 30 47 D In 7 - 8 14 30 47 D Out 7 - 8 10 26 43
A In 5 13 29 46 D In 9 - 10 1 2 9 25 42 D Out 9 - 10 1 2 5 21 38
A In 6 12 28 45 D In 11 - 12 8 24 41 D Out 11 - 12 4 20 37
A In 7 11 27 44 D In 13 - 14 7 23 40 D Out 13 - 14 3 19 36
A In 8 10 26 43 D In 15 - 16 6 22 39 D Out 15 - 16 2 18 35
A In 9 1 3 17 33 50 D In 17 - 18 2 2 17 33 50 D Out 17 - 18 2 2 13 29 46
A In 10 16 32 49 D In 19 - 20 16 32 49 D Out 19 - 20 12 28 45
A In 11 15 31 48 D In 21 - 22 15 31 48 D Out 21 - 22 11 27 44
A In 12 14 30 47 D In 23 - 24 14 30 47 D Out 23 - 24 10 26 43
A In 13 13 29 46 D In 25 - 26 2 2 9 25 42 D Out 25 - 26 2 2 5 21 38
A In 14 12 28 45 D In 27 - 28 8 24 41 D Out 27 - 28 4 20 37
A In 15 11 27 44 D In 29 - 30 7 23 40 D Out 29 - 30 3 19 36
A In 16 10 26 43 D In 31 - 32 6 22 39 D Out 31 - 32 2 18 35
