3.1.1 48 Track Digital 48 Digital I/Os 2 QDC Cards
Analog Inputs Analog Outputs Digital Inputs Digital Outputs
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
D In 1 - 2 1
2
17 33 50 D Out 1 - 2 1
2
13 29 46
D In 3 - 4
16 32 49 D Out 3 - 4
12 28 45
D In 5 - 6
15 31 48 D Out 5 - 6
11 27 44
D In 7 - 8
14 30 47 D Out 7 - 8
10 26 43
D In 9 - 10 1
2
9 25 42 D Out 9 - 10 1
2
5 21 38
D In 11 - 12
8 24 41 D Out 11 - 12
4 20 37
D In 13 - 14
7 23 40 D Out 13 - 14
3 19 36
D In 15 - 16
6 22 39 D Out 15 - 16
2 18 35
D In 17 - 18 1
3
9 25 42 D Out 17 - 18 1
3
5 21 38
D In 19 - 20
8 24 41 D Out 19 - 20
4 20 37
D In 21 - 22
7 23 40 D Out 21 - 22
3 19 36
D In 23 - 24
6 22 39 D Out 23 - 24
2 18 35
D In 25 - 26 1
1
9 25 42 D Out 25 - 26 1
1
5 21 38
D In 27 - 28
8 24 41 D Out 27 - 28
4 20 37
D In 29 - 30
7 23 40 D Out 29 - 30
3 19 36
D In 31 - 32
6 22 39 D Out 31 - 32
2 18 35
D In 33 - 34 2
2
17 33 50 D Out 33 - 34 2
2
13 29 46
D In 35 - 36
16 32 49 D Out 35 - 36
12 28 45
D In 37 - 38
15 31 48 D Out 37 - 38
11 27 44
D In 39 - 40
14 30 47 D Out 39 - 40
10 26 43
D In 41 - 42 2
2
9 25 42 D Out 41 - 42 2
2
5 21 38
D In 43 - 44
8 24 41 D Out 43 - 44
4 20 37
D In 45 - 46
7 23 40 D Out 45 - 46
3 19 36
D In 47 - 48
6 22 39 D Out 47 - 48
2 18 35
