48
3.1.4 48 Track Analog plus Digital 48 Digital I/Os 48 Analog Inputs 48 Analog Outputs
Analog Inputs Analog Outputs Digital Inputs Digital Outputs
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
Port QDC Con Pins
+ GND -
A In 1 1 1 173350 A Out 1 1 1 9 2542 D In 1 - 2 1 2 173350 D Out 1 - 2 1 2 132946
A In 2 163249 A Out 2 8 2441 D In 3 - 4 163249 D Out 3 - 4 122845
A In 3 153148 A Out 3 7 2340 D In 5 - 6 153148 D Out 5 - 6 112744
A In 4 143047 A Out 4 6 2239 D In 7 - 8 143047 D Out 7 - 8 102643
A In 5 13 29 46 A Out 5 5 21 38 D In 9 - 10 1 2 9 25 42 D Out 9 - 10 1 2 5 21 38
A In 6 12 28 45 A Out 6 4 20 37 D In 11 - 12 8 24 41 D Out 11 - 12 4 20 37
A In 7 11 27 44 A Out 7 3 19 36 D In 13 - 14 7 23 40 D Out 13 - 14 3 19 36
A In 8 10 26 43 A Out 8 2 18 35 D In 15 - 16 6 22 39 D Out 15 - 16 2 18 35
A In 9 1 3 17 33 50 A Out 9 1 3 9 25 42 D In 17 - 18 2 2 17 33 50 D Out 17 - 18 2 2 13 29 46
A In 10 16 32 49 A Out 10 8 24 41 D In 19 - 20 16 32 49 D Out 19 - 20 12 28 45
A In 11 15 31 48 A Out 11 7 23 40 D In 21 - 22 15 31 48 D Out 21 - 22 11 27 44
A In 12 14 30 47 A Out 12 6 22 39 D In 23 - 24 14 30 47 D Out 23 - 24 10 26 43
A In 13 13 29 46 A Out 13 5 21 38 D In 25 - 26 2 2 9 25 42 D Out 25 - 26 2 2 5 21 38
A In 14 12 28 45 A Out 14 4 20 37 D In 27 - 28 8 24 41 D Out 27 - 28 4 20 37
A In 15 11 27 44 A Out 15 3 19 36 D In 29 - 30 7 23 40 D Out 29 - 30 3 19 36
A In 16 10 26 43 A Out 16 2 18 35 D In 31 - 32 6 22 39 D Out 31 - 32 2 18 35
A In 17 2 1 17 33 50 A Out 17 2 1 9 25 42 D In 33 - 34 3 2 17 33 50 D Out 33 - 34 3 2 13 29 46
A In 18 16 32 49 A Out 18 8 24 41 D In 35 - 36 16 32 49 D Out 35 - 36 12 28 45
A In 19 15 31 48 A Out 19 7 23 40 D In 37 - 38 15 31 48 D Out 37 - 38 11 27 44
A In 20 14 30 47 A Out 20 6 22 39 D In 39 - 40 14 30 47 D Out 39 - 40 10 26 43
A In 21 13 29 46 A Out 21 5 21 38 D In 41 - 42 3 2 9 25 42 D Out 41 - 42 3 2 5 21 38
A In 22 12 28 45 A Out 22 4 20 37 D In 43 - 44 8 24 41 D Out 43 - 44 4 20 37
A In 23 11 27 44 A Out 23 3 19 36 D In 45 - 46 7 23 40 D Out 45 - 46 3 19 36
A In 24 10 26 43 A Out 24 2 18 35 D In 47 - 48 6 22 39 D Out 47 - 48 2 18 35
A In 25 2 3 17 33 50 A Out 25 2 3 9 25 42
A In 26 16 32 49 A Out 26 8 24 41
3 QDC Cards
