Falcon Kitchener - Governor Adjustment and Pressure Testing

WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON
Disconnect from electricity and gas before servicing. Check appliance is safe when you have nished.
33
Set the Governor
Unscrew the governor’s brass top. In the base of the brass top
is a plastic snap-in converter device (Fig. 8.4). To convert the
governor, snap the device out of the top and ret it the other
way round. The snap-in converter device is marked to show
the gas for which it is set (Fig. 8.5).
Make sure the device is secure in the top cap and ret the cap
to the governor.
Pressure Testing
The pressure test point is accessible on the inlet pipe at the
rear. Remove the test nipple screw and t a pressure gauge to
the test point. Turn on and light two of the hotplate burners.
For Propane X cookers the pressure should be 2.54 kPa.

Make sure that the appliance is gas sound.

Check the operation of all the burners.
Affix Label
Stick the appropriate gas label over the natural gas part of the
appliance data label.
ArtNo.102-0007 - Maxitrol converter device positions
Fig. 8.5
ArtNo.103-0006 - Maxitrol cap & converter
Nut
Snap-in converter device
Fig. 8.4
