Manual Bypass Function
A manual bypass button is located on the SSG front panel. When the UPS is operating from utility in
the normal on-line state, depressing this button will cause the UPS to transfer to bypass. Depressing
the bypass button again will return the UPS to the normal on-line condition.
Automatic Bypass Transfers
The SSG Series UPS will automatically switch to bypass to energize the connected load when the
UPS is first turned on, encounters an overload, encounters an over temperature condition, or upon a
UPS failure condition. Should any of these events occur, the UPS will transfer to bypass mode,
sound an audible alarm and provide a "bypass" indication on the LCD display.
Output Filter
As with the input filter stage, the output filter maintains conducted (EMC) and RFI levels below FCC
Class B limits.
3. 0 INSTALLATION
Unpacking
The SSG Series UPS may be shipped in a number of boxes, depending on the model and
configuration ordered. The number of boxes you have received should be as indicated:
MODEL BATTERY MODULE NUMBER OF BOXES
SSG1.5KRM-X n/a (internal battery pack) 1 box shipped
SSG2.2KRM-X 1 battery module 2 boxes shipped
SSG3KRM-X 1 battery module 2 boxes shipped
If you have not received the proper number of boxes, please contact Falcon Electric Customer
Service at 1-800-842-6940.
This UPS is shipped complete with all cables required for operation, including UPSILON software,
and rackmount ears for 19" rackmount shelf mounting. A full list of the box contents is provided as
follows:
SSG1.5KRM-X SSG2.2KRM-X / SSG3KRM-X
Box 1 contains: Box 1 contains:
UPS module with fitted battery pack UPS module without battery
RS-232 cable RS-232 cable
Software CD Software CD
Manual Manual
19" rack ears (+ screws) 19" rack ears (+ screws)
Box 2 contains:
Battery module
Battery connection cable
Keyhole hardware
19" rack ears (+ screws)
1 set of mounting plates & securing hardware
9
