18
6.5 Changing the Quick Release
Turn the locking ring clockwise until it reaches the end
of the shaft. Continue to rotate the locking ring clockwise
while holding the steering axle in place with your other
hand. The locking ring will slowly push the Quick Release
out.
Unravel the cables inside the wheel base to give you more space.
Disconnect the two cables by lifting the locking tabs of each connector.
IMPORTANT: DO NOT pull out the steering axle forcefully by hand
other wise it is possible to tear off the cables inside the steering axle.
Once the locking ring begins to push the Quick Release out, it should
come out very easily.
Make sure your wheel base is off and unplugged.
Position the locking ring until it touches the rubber gasket,
but do not tighten. This keeps the rubber gasket in place.
Now loosen the bolts of the black clamp ring at the end of
the steering axle.
