LE-03MB - User manual
30
Bytes
Parameters
Data structure
Notice
4
Header telegram
68 5D 5D 68
Header of RSP_UD telegram
3
08 A 72
C field=08 address A CI field 72
4
78 65 34 21
Identification number =12345678
2
24 40
Manufacturer ID 4024
1
01
Generation 1
1
02
Energy meter
1
55
ACCESS NO
1
00
STATUS
2
00 00
Signaturе
6
Current total
active energy
0C
DIF: 8 digit BCD , Current value
04
VIF: 10 W (0.01 kW)
78 56 34 12
123456.78 kWh
7
Current import
active energy
0C
DIF: 8 digit BCDFIE, Current value
04
VIF: 10 W (0.01 kW)
78 56 34 12
123456.78 kWh
7
Current export
active energy
0C
DIF: 8 digit BCDFIE, Current value
04
VIF: 10 W (0.01 kW)
78 56 34 12
123456.78 kWh
6
Current resettable total
active energy
0C
DIF: 8 digit BCD, Current value
04
VIF: 10 W (0.01 kW)
78 56 34 12
123456.78 kWh
7
Current resettable import
active energy
0C
DIF: 8 digit BCDFIE, Current value
04
VIF: 10 W (0.01 kW)
78 56 34 12
123456.78 kWh
7
Current resettable export
active energy
0C
DIF: 8 digit BCDFIE, Current value
04
VIF: 10 W (0.01 kW)
78 56 34 12
123456.78 kWh
