F&F LE-03MB - Page 33

LE-03MB - User manual
33
Bytes
Parameters
Data structure
Notice
4
Header telegram
68 90 90 68
Header of RSP_UD telegram
3
08 A 72
C field =08 address A CI field 72
4
78 65 34 21
Identification number =12345678
2
24 40
Manufacturer ID 4024
1
01
Generation 1
1
02
Energy meter
1
55
ACCESS NO
1
00
STATUS
2
00 00
Signature
6
L1 voltage
0B
DIF: 6 digit BCD
FD
VIF: FD
47
VIFE: 0.01 V
56 34 12
1234.56 V
6
L2 voltage
0B
DIF: 6 digit BCD
FD
VIF: FD
47
VIFE: 0.01 V
56 34 12
1234.56 V
6
L3 voltage
0B
DIF: 6 digit BCD
FD
VIF: FD
47
VIFE: 0,01 V
56 34 12
1234,56 V
6
L1 - L2 Voltage
0B
DIF: 6 digit BCD
FD
VIF: FD
47
VIFE: 0.01 V
56 34 12
1234.56 V
