Chapter 11 Port Explanation
96
11.2.1.3 Typical Circuit of Using Powder
1
Low pressure
preheat
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
High pressure
cutting oxygen
Torch up
Torch down
Ignite
Low pressure
cutting oxygen
Mid-pressure
preheat
exhaust
Plasma arc
starting
High pressure
perheat
Low rate at
corner
Plasma
positioning
Spray powder
Raise powder
Enable height
adjusting
Powder preheating
unused
unused
unused
unused
+24V
+24V
+24V
24VG
24VG
COM
Caution: All outputs can be
effective high or effective low,
system default is effective low .
（connecting to system supply
24VG,Or connecting to the +24V
side of external 24V switching
power supply.）
+24V
Ignition control(effective low)
Spray powder control(low active)
Raise or stir powder control(low active)
Powder preheat (low active)
Fig 11.6 powder typical connection
