FangLing F2300(A/B) - Wiring Connection of F1500 System

Chapter 14 Shanghai FangLing F1500 Remote Controller
117
14.5 Wiring Connection Figure of F1500 and FangLing
Numerical Control System
OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 24V+ 24VG
Output ports
of F1500
remote
controller
8 7 10 9 12 25
Input ports of F2000 series
digital control system
Fig 14.4 Wiring connection interpret of F2000 series numerical control system and remote
controller
Note：wiring connection of F1500 remote controller and F2000 series remote
controller please refer to “11.1.2 Remote controller input” section，type setting of
remote controller please refer to “8.7.6 Option” section.
