FangLing F2300(A/B) - Connection with HYD THC

Chapter 14 Shanghai FangLing F1500 Remote Controller
116
Table 14.1：8421 code receive mode (the 1
st
bit of jumper switch has jumper cap)
Sender
Key
OUT1-OUT4
OUT9-OUT16
OUT5 OUT6 OUT7 OUT8
S+/Speed
Off On Off Off Off
S-/Speed
Off Off On On On
↑
Off On Off On Off
↓
Off On Off Off On
←
Off Off On Off Off
→
Off On On On Off
Mode
Off On On On On
T↑
Off On On Off On
T↓
Off On On Off Off
Start
Off Off On On Off
Stop
Off On Off On On
Back
Off Off Off On Off
Foward
Off Off Off On On
Ignition
Off Off On Off On
CutOxy
Off Off Off Off On
Table 14.2: Independent IO mode (P2P mode, the 8th bit doesn’t have jumper cap)
Sender key Open output port Close output port
→
OUT1 Other output ports
←
OUT2 Other output ports
↑
OUT3 Other output ports
↓
OUT4 Other output ports
S-/Speed
OUT5 Other output ports
S+/Speed
OUT6 Other output ports
Start
OUT7 Other output ports
Stop
OUT8 Other output ports
Mode
OUT9 Other output ports
T↑
OUT10 Other output ports
T↓
OUT11 Other output ports
Foward
OUT12 Other output ports
Back
OUT13 Other output ports
Ignition
OUT14 Other output ports
CutOxy
OUT15 Other output ports
