9
How to Hang Your Ceiling Fan
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advise, as it must be
grounded for safe operation.
WARNING
The fan must be hung with at least 7’ of clearance
from floor to blades. (Figure 2)
WARNING
To avoid possible fire or shock, be sure electricity is
turned off at the main fuse box before hanging.
(Figure 1)
Figure 2
CEILING
FLOOR
NO LESS
THAN
7 FEET
Figure 1
MAIN FUSE BOX
1. Securely attach the hanger bracket to the outlet
box using the outlet box screws and washers
supplied with the outlet box (Figure 3).
The outlet box must be securely anchored. Hanger
bracket must seat firmly against outlet box. If the outlet
box is recessed, remove wall board until bracket
contacts box. If bracket and /or outlet box are not
securely attached, the fan could wobble or fall.
WARNING
2. Carefully lift the fan and seat the downrod/hanger
ball assembly on the hanger bracket that was just
attached to the outlet box. Be sure the groove in
the ball is lined up with tab on the hanger bracket
(Figure 4).
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
WARNING
!
To avoid possible shock, do not pinch wires between
the hanger ball assembly and the hanger bracket.
WARNING
!
OUTLET BOX
SCREW (2)
Flat Washer
(Supplied with
Outlet Box)
TAB
Figure 3
OUTLET BOX
Figure 4
To Next Page
