Before discarding packaging materials, be certain all parts have been removed
Parts List
Model FP4520**
Ref. # Description Part #
1 Hanger Bracket Assembly with Screws AP255BL
2 Downrod/Hanger Ball Assembly Containing:
ADR1-6**
2a Hanger Ball Assembly
2b Downrod
2c Clevis Pin
2d Hairpin Clip
3 Ceiling Canopy PG155**
4 Canopy Screw Cover AP260**
5 Motor Coupling Cover with Grommet AP1115**
6 Fan Motor Assembly AMA4520**
7 Floating Rings (2) P452050**
8 Blade Set (2) AP452040
9 Switch Cup Adapter Assembly P452005
10 Switch Cup Assembly with Wiring Harness AP452006BL
11 Lower Cover Assembly AP452070**
12 Wall Control CW40
13
Hardware Bag Containing: HDWFP4520**
Blade Balance Kit (BALKT)
HDWHW4520**
Counterweight, Floating Rings
Nameplate Plug Assembly
¼˝–20 x 15 mm Pan Head Screw with Lock Washer (4)
Wire Connectors (4)
Blade Mounting Hardware Bag Containing:
HDWBM4520
3
/16–24 x 15 mm Washer Head Screw (7)
Fiber Washers (7)
Phillips Screwdriver, 4˝
How To Order Parts
When ordering repair parts, always
give the following information:
• Part Number
• Part Description
• Fan Model Number
Contact your retail store for repair parts.
¾¾
Insert FINISH CODES (Refer to fan model number located on downrod support)
12
To Next Page
