Page #10 background imageLoading...
Page #10 background image
CAUTION: INCORRECT WIRE CONNECTION COULD
DAMAGE THIS RECEIVER.
NOTE: If fan or supply wires are different colors than indicated, haYHWKLVXQLWLQVWDOOHGE\DTXDOL¿HGHOHFWULFLDQ
Figure 4
MAIN FUSE BOX
Figure 2
Figure 1
Figure 3
To avoid possible electrical shock, be sure electricity
gniriw erofeb xob esuf niam eht ta ffo denrut si
(Figure 2).
WARNING
NOTE:
If you are not sure if the outlet box is
grounded, contact a licensed electrician for advice, as
LWPXVWEHJURXQGHGIRUVDIHRSHUDWLRQ
x 8
WIRE
CONNECTORS
RECEIVER HARDWARE USED:
2. Slide the receiver into the hanger bracket as shown in
Figure 3.
WARNING
3. Connect wires using connectors as shown in Figure 4.
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors. Do not operate fan until the blades are in
place. Noise and motor damage could result.
%/8(
%/$&.
:+,7(
%/$&.
:+,7(
/
1
$&32:(5
5('
*5$<
<(//2:
<(//2:
*5((1
LISTED
OUTLET
BOX
WHITE
BLACK
BLUE
BLACK & WHITE
GREEN-Ground Wire
From Hanger Bracket
GREEN-Ground Wire
From Hanger Ball
GREEN-Ground Wire
From Ceiling
YELLOW
GRAY
RED
GREEN / YELLOW
- Ground Wire (2)
From Receiver
*5281'
+$1*(5
%5$&.(7
+$1*(5
%$//
'&02725
%/$&.
$17(11$
Figure 5
How to Wire Your Ceiling Fan
5HFHLYHU
5HFHLYHU
5HFHLYHU8QLW
+DQJHU%UDFNHW
NOTE: Supply wires
omitted for clarity
4. After connections have been made, slide the receiver
into the hanger bracket, taking care not to pinch the
wires and put the white and green leads to one side and
the black leads towards the other side. The wires should
be spread apart with the grounded conductor and the
equipment-grounding conductor on one side of the outlet
box and the ungrounded conductor on the other side.
(Figure 5)
10
Dip Switch
ON
1 2 3 4 5
1. To set the code on receiver unit, slide dip switches to
the same positions as set on the remote. (Figure 1)
NOTE: The remote unit has 32 different code
FRPELQDWLRQV7RSUHYHQWSRVVLEOHLQWHUIHUHQFHIURPRUWR
other remote units, simply change the combination code
LQWKHUHPRWHDQGUHFHLYHU
NOTE: Factory setting is all up. Do not use this position.
