Fanvil PA2S User Manual

41
Picture 25- SIP
Table 15 - SIP
Parameters
Description
Register Settings
Line Status
Display the current line status at page loading.
To get the up to date line status, user has to
refresh the page manually.
Server Address
Enter the IP or FQDN address of the SIP server
Server Port
Enter the SIP server port, default is 5060
Authentication User
Enter the authentication user of the service
account
Authentication Password
Enter the authentication password of the service
account
Username
Enter the username of the service account.
Display Name
Enter the display name to be sent in a call
request.
Activate
Whether the service of the line should be
activated
Realm
Enter the SIP domain if requested by the service
provider
SIP Proxy Server Address
Enter the IP or FQDN address of the SIP proxy
server
Proxy Server Port
Enter the SIP proxy server port, default is 5060
Proxy User
Enter the SIP proxy user
Proxy Password
Enter the SIP proxy password
Backup Proxy Server Address
Enter the IP or FQDN address of the backup
proxy server
Backup Proxy Server Port
Enter the backup proxy server port, default is
5060
Basic Settings
Enable Auto Answering
Enable auto-answering, the incoming calls will
be answered automatically after the delay time
Auto Answering Delay
Set the delay for incoming call before the system
automatically answered it
Call Forward Unconditional
Enable unconditional call forward, all incoming
calls will be forwarded to the number specified in

Fanvil PA2S Specifications

General

Supported protocols	SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 PPPoE L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069
Full duplex	Yes
VPN support	L2TP / OpenVPN
Ethernet LAN data rates	10, 100 Mbit/s
WAN connection	Ethernet (RJ-45)
Headphone connectivity	3.5 mm
Ethernet LAN (RJ-45) ports	2
Package depth	58 mm
Package width	147 mm
Package height	114 mm
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Mounting type	Desktop/Wall mounting
Product color	Black
LED indicators	Network, Status
Enclosure material	Aluminum
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729B, OPUS

Weight and Dimensions

Depth	28 mm
Width	113 mm
Height	83 mm
