Fanvil PA2S User Manual

49
answer the call after specific delay.
Enable Intercom Mute
Enable mute mode during the intercom call
Enable Intercom Tone
If the incoming call is intercom call, the phone plays the intercom tone
Enable Intercom Barge
Enable Intercom Barge by selecting it, the phone auto answers the
intercom call during a call. If the current call is intercom call, the phone
will reject the second intercom call
Response Code Settings
Busy Response Code
Set the SIP response code on line busy
Reject Response Code
Set the SIP response code on call rejection
9.17 Phone settings >> media
Picture 29- Media Settings
Table 18- Audio Settings
Parameters
Description
Codecs Settings
Select the enabled and disabled voice codecs
codec:G.711A/U,G.722,G.723,G.729,G.726-32,
ILBC,AMR,AMR-WB
Audio Settings
Default Ring Type
Set the default ring type. If the caller ID of an incoming call

Fanvil PA2S Specifications

General

Supported protocols	SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 PPPoE L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069
Full duplex	Yes
VPN support	L2TP / OpenVPN
Ethernet LAN data rates	10, 100 Mbit/s
WAN connection	Ethernet (RJ-45)
Headphone connectivity	3.5 mm
Ethernet LAN (RJ-45) ports	2
Package depth	58 mm
Package width	147 mm
Package height	114 mm
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Mounting type	Desktop/Wall mounting
Product color	Black
LED indicators	Network, Status
Enclosure material	Aluminum
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729B, OPUS

Weight and Dimensions

Depth	28 mm
Width	113 mm
Height	83 mm
