Faraone ELEVAH 40 MOVE PICKING - Overall Dimensions

USE AND MAINTENANCE MANUAL - SECTION 2
STOCK PICKER ELEVAH 40 MOVE PICKING / B PICKING - Rev. 14_2021
Page 2-2
OVERALL DIMENSIONS AND CLEARANCES
ELEVAH 40 MOVE PICKING
Measurements expressed in mm
1730
670 980
290
1360
700
500
715 615
550
1950
2975
