USE AND MAINTENANCE MANUAL - SECTION 4
STOCK PICKER ELEVAH 40 MOVE PICKING / B PICKING - Rev. 14_2021
Page 4-15
ELECTRIC LOADING PLATFORM
The electrically-lifted loading platform is available as an optional extra instead of the removable
loading platform.
The control to move the electric loading platform is found in the cage control console, as indicated
below.
Loading platform up/down control
• Turn the selector to the LEFT to LOWER the loading platform.
• Turn the selector to the RIGHT to RAISE the loading platform.
NOTE: The position of the selector with removable key shown in the picture may vary depending on the
control console of the machine model where the system is installed.
Electric loading platform closure
The optional loading platform in the ELEVAH 40 MOVE PICKING / B PICKING machines can be
closed for easier movement of the machines in confined areas.
To close the loading platform proceed as follows:
1. Raise the loading platform up to the maximum height using the specific control;
2. Hold the loading platform with both hands and make it rotate upwards until it is blocked;
3. Use the specific control to lower the loading platform.
