USE AND MAINTENANCE MANUAL - SECTION 4
STOCK PICKER ELEVAH 40 MOVE PICKING / B PICKING - Rev. 14_2021
REMOVABLE LOADING PLATFORM (OPTIONAL)
The removable loading platform has a maximum capacity of 100 kg and can be manually secured in
eight positions, as required.
Installing the objects holder platform
Insert the platform from the front of the machine into one of the possible positions , taking care to
insert the pin (1) correctly in one of the grooves (2) available in the column.
Fully insert the locking bracket into the relevant hole and hook the special safety spring catch in the
hole at the other end of the bracket.
Remove the objects holder platform by carrying out the previous steps in inverse order and place it
in a suitable place.
CAUTION
USE THE LOADING PLATFORM ONLY AFTER CHECKING THAT IT IS BLOCKED
CORRECTLY
