USE AND MAINTENANCE MANUAL - SECTION 2
STOCK PICKER ELEVAH 40 MOVE PICKING / B PICKING - Rev. 14_2021
BASIC CONSTRUCTION DATA
MACHINE FRAME: The frame of the machine (called base) is made completely of aluminium
profiles with rectangular sections. All essential components for normal machine operation in stable
conditions are installed on the frame.
EXTENSIBLE STRUCTURE: The extensible structure (column) consists of extruded galvanised iron
profiles (called extensions) that slide on each other by means of nylon pads.
A synchronised three-rod oil hydraulic cylinder is installed inside the column, powered by the
hydraulic unit, to lift the structure.
CAGE, OBJECTS HOLDER TRAY AND LOADING PLATFORM: The cage, the objects holder tray
and the loading platform are made entirely of galvanised iron profiles. The base platforms are built
with 3 mm thick, non-slip, aluminium chequer plate.
EXPOSURE TO VIBRATIONS: The stock picker does not produce vibrations that pose a risk to the
health of operators. The weighted acceleration that the whole body is exposed to is less than 0.5
m/s
2
SOUND EMISSIONS: The A-weighted emission sound pressure level is below 70dB
REFERENCES TO STANDARDS
The machine has been manufactured in accordance with the health and safety requirements of
Machinery Directive 2006/42/EC and harmonised standard UNI EN 3691-1:2020.
In accordance with ISO 22915-1:2020, the Stock Picker sample was tested by the manufacturer
using:
• Static stability tests
And it was subjected to the following additional tests:
• Overload test
• Operation tests
The results of the tests and the conformity of the machine are reported in the document in Annex 5.
