USE AND MAINTENANCE MANUAL - SECTION 4
STOCK PICKER ELEVAH 40 MOVE PICKING / B PICKING - Rev. 14_2021
SECTION 4. CONTROLS, WARNING LIGHTS AND MACHINE OPERATION
INTRODUCTION
CAUTION
THE MANUFACTURER DOES NOT HAVE ANY DIRECT CONTROL OVER MACHINE
APPLICATION AND OPERATION. THE USER AND OPERATOR ARE REQUIRED TO COMPLY
WITH THE CORRECT SAFETY PROCEDURES.
Stock pickers model ELEVAH 40 MOVE PICKING / B PICKING are electric machines equipped with
a cage assembled onto a lifting mechanism with aluminium uprights.
The self-propelled stock pickers are DESIGNED TO CARRY, LIFT, STACK OR ARRANGE LOADS
ON SHELVING AND CONTROLLED BY AN OPERATOR STATIONED IN THE DRIVER'S
POSITION, WHICH CAN BE RAISED AT THE SAME TIME AS THE LOAD HANDLING DEVICE.
The main control station is located in the cage. The operator can drive the machine and lift and lower
the cage from the control console of the cage (when machine is self propelled in “MOVE PICKING”
transport position) or can only lift and lower the cage (for the “B PICKING” manually pushed
machine).
The vibrations generated by the machine do not constitute any danger for the operator who is inside
the cage.
The continuous sound pressure level (A-weighted) in the cage is less than 70 db (A).
MACHINE OPERATION
Preliminary operations
It is necessary for the following control conditions to be satisfied, before activating the machine from
the controls in the cage.
• The battery voltage must be sufficient to operate the machine;
• The emergency stop switch with removable key, located on the control station in the cage
must be on RESET.
CHARGING THE BATTERY
The machine is fitted with a battery charger with AC voltage input/DC voltage output. The battery
charger automatically stops charging when the batteries are fully charged.
CAUTION
KEEP SPARKS, NAKED FLAMES OR CIGARETTES AWAY FROM THE BATTERIES.
PROVIDE ADEQUATE VENTILATION WHILE CHARGING.
NOTE: when the battery charger is connected to an AC socket, the transmission function of the
machine is disabled.
