Faraone ELEVAH 40 MOVE PICKING - Page 14

USE AND MAINTENANCE MANUAL - SECTION 2
STOCK PICKER ELEVAH 40 MOVE PICKING / B PICKING - Rev. 14_2021
Page 2-5
ELEVAH 40 B PICKING LIFTER TECHNICAL DATA
Value
Weight of the machine (overall):
Refer to the CE plate affixed to
the machine.
Maximum resting force on the ground (per wheel/stabiliser (*):
Refer to the CE plate affixed to
the machine.
Machine height (in transport position):
173 cm
Machine base overall dimensions:
1360 cm x 71 cm
Maximum hydraulic system pressure:
~ 60 bar
Required amount of oil for the hydraulic system:
~ 2.5 Litres
Power supply
2 x 12V 50Ah Lead acid
batteries
Operators in the cage:
1
Maximum capacity of the cage + loading platform (manual or
electric):
200 kg
Maximum capacity of the loading platform (manual or electric):
100 kg
Maximum cage height (from the ground to the floor of the cage):
1.95 m
Maximum cage height with self-propeller (from the ground to the
floor of the cage):
N.A.
Maximum dimensions of the loading platform (manual or
electric):
~ 50 cm x 70 cm
Internal dimensions of the cage:
~ 61 cm x 55 cm
Max shifting speed in transport position:
N.A.
Maximum self-propelled movement speed at a height:
N.A.
Maximum cage rising speed:
0.15 m/s
Maximum cage descending speed:
0.15 m/s
Maximum longitudinal / transversal gradient in the transport
position:
15%
Maximum longitudinal / transversal gradient in the raised
position:
“Levelled” base
* Maximum force per stabiliser considering that 70% of the weight of the machine plus the maximum load inside the cage
are entirely distributed on one side only of the platform (entirely asymmetrical load)
