EXHITO series INTERCOMMUNICATING INTERCOMS (2 to 8 us-
ers)
Q.ty Article Description
... EX320 Exhito series modular intercom
... EX301 Single button module
1 PRS226E Power supply-switcher
... Refers to number of users.
Working instructions. See page 183.
Notes
- Do not forget to connect terminals C and the common terminal of all the
additional buttons.
- Do not use KEY button for intercommunication calls (5 terminal).
- For wires dimensioning refer to the installation instructions and table on
page 146.
Table for choosing intercoms and accessories for the required type of installation
Number of inter- Exhito Exhito Studio Compact
communicating EX320 EX301 EX310 EX301 ST 720W ST 701 KM810W ST701
2 20202222
3 333336
448 412
5515 520
6624 630
7735 742
8848
Si 200L/7
STUDIO series INTERCOMMUNICATING INTERCOMS (2 to 7 us-
ers)
Q.ty Article Description
... ST 720W Studio series modular intercom
... ST 701 Single button module
1 PRS226E Power supply-switcher
... Refers to number of users.
Working instructions. See page 183.
Notes
- Do not forget to connect all terminals C of the additional buttons.
- Do not use KEY button for intercommunication calls (5 terminal).
- For wires dimensioning refer to the installation instructions and table on
page 146.
E
X
-
S
T
-
K
M
Si 200L/8
COMPACT series INTERCOMMUNICATING INTERCOMS (max.
2 users)
Q.ty Article Description
2 KM810W Compact series intercom
2 ST 701 Single button module
1 PRS226E Power supply-switcher
Working instructions. See page 183.
Notes
- Do not use KEY button for intercommunication calls (5 terminal).
- For wires dimensioning refer to the installation instructions and
table on page 146.
EXHITO series INTERCOMMUNICATING INTERCOMS (max. 3
users)
Q.ty Article Description
... EX310 Exhito series intercom
... EX301 Single button module
1 PRS226E Power supply-switcher
... Refers to number of users.
Working instructions. See page 183.
Notes
- Do not forget to connect terminals C and the common terminal of
the additional button.
- Do not use KEY button for intercommunication calls (5 terminal).
- For wires dimensioning refer to the installation instructions and
table on page 146.
