FARFISA INTERCOMS ECHOS User Manual

15
(MT11 - Gb2012)
K
M
-
P
T
1+1
INTERCOMS *
4+1
VIDEOINTERCOMS
INTERNAL STATIONS
KM811W. White electronic intercom with 1
push-button, spiral cord, electronic microphone
and possibility to insert an additional ST701
push-button and a SR41 or SM50 module
(description and characteristics of the mod-
ules on page 13). Wall-mountable with expan-
sion plugs or wall box.
Terminals
1 audio line, bell and door release control
3 ground
6 output electronic bell *
7 ground. Connected to terminal 3 with jumper
W1 *
A1 floor call input
* terminals to be used when installing the private
conversation module SM50 in the intercom.
INTERCOMS
2
16
/
9
65
3
"
8
/
3
86
8
"
16
/
5
211
"
ST701
Mounting of the additional button ST701.
INTERCOMS
PT511EW. White electronic intercom with 1
push-button, spiral cord, electronic microphone
and possibility to insert SR41 or SM50 module
(description and characteristics of the mod-
ules on page 13). Wall-mountable with expan-
sion plugs or wall box.
Terminals
1 audio line, bell and door release control
3 ground
6 output electronic bell *
7 ground. Connected to terminal 3 with jumper
W1 *
A1 floor call input
* terminals to be used when installing the private
conversation module SM50 in the intercom.
3
"
16
/
1
2
8
"
"
16
16
/
/
13
1
77.572
214
3
"
4
/
1
7
"
16
/
3
83
182
PROJECT SERIES
COMPACT SERIES
