FAS-CAM F701 - Page 12

MODEL: F701-DR
INPUT: 5V 2A
MADE IN CHINA
Reset Button
Press with a Pin to reset the Front
Camera when needed
Length%
90-mm (3.54-inch)
Width%
22.97-mm (0.90-inch)
3
Product Overview
3.2 Part Names
‣
3.2.3 F701-DR Front Camera Bottom View and Dimension
3: Product Overview
F701-DR
Dimension
Length
Width
Height
Millimeter
90
52
22.97
Inch
3.54
0.90
2.05
