Fasep 2000 srl Rev. 1.8
Balatron 222/212: User’s Manual 23 January 2020
4-1
FIG. 10
FIG. 11
FIG. 12
4 CALIBRATION
4.1 How to calibrate the Wheel Balancer (USER)
NOTE the following symptoms indicate need for calibration:
a) check calibration program fails.
b) constant low or high weight readings.
c) indicated point of unbalance constantly wrong
d) more than 2 spins required to balance wheels repeatedly
Switch on the wheel balancer.
Press <SET> when SOF X.XX
(software version) is displayed.
ATTENTION select mode
CAL USR
Spin the empty shaft ( Fig. 9).
Place a wheel on the flange ( Fig. 10).
Put the calibration weight (Fig. 11).
End of calibration.
Press <MODE/ESC> to return to normal
balancing mode.
NOTE technical calibration is only available for qualified personnel.
