Fasep 2000 srl Rev. 1.8
Balatron 222/212: User’s Manual 23 January 2020
4-2
FIG. 14
FIG. 15
4.2 How to check the calibration of Wheel Balancer (USER)
ATTENTION select mode
CAL USR
Press <+/-> to select CAL TEST
Place a wheel on the flange ( Fig. 13).
Put the calibration weight ( Fig. 14).
Press 10 <FINE> to see actual values.
160-0 (±3) is correct result.
When all LED (left side) are lit,
calibration weight must be at exactly 6
o’clock.
If no, press 11 <FUNC> to calibrate
position.
Turn the wheel until the calibration
weight is located at 6 o’clock.
Press <SET> to calibrate.
Press <MODE/ESC> to return to normal
balancing mode.
NOTE technical calibration is only available for qualified personnel.
FIG. 16
