Fasep 2000 srl Rev. 1.3
Balatron B110, B210: User’s Manual 15 July 2013
8-2
Fig.24 : Balatron B110/B210 measures
APPENDIX
A: Technical Data
Absorbed power 5W
Speed Balancing 75/125RPM
Measuring time 4-15 seconds
Precision ±1grs (±1/28 ounce)
Wheel dimensions Rim Diameter from 8" (200mm) to 26" (650mm)
Wheel Diameter (m ax, with cover) 34" (850mm)
Rim Width (max, with cover) 16" (410mm)
Wheel Weight (max) 70Kg (155Lbs)
Wheel balancer dimensions
B110 B210
L (mm) 1100 1030
L1 (mm) 500 500
P (mm) 340 430
P1 (mm) 550 550
H (mm) 380 940
Weight (kg) 44 65
B: Environmental Data, Safety Features and
Requirements
Environmental Data
[Operating conditions]
This unit is designed for indoor use only.
Temperature: 0 to 45°C Relative Humidity: 5 to 80% a 40°
[Storage conditions]
Package is designed for indoor storage only.
Temperature: -25° to 70°C Relative humidity: 5 at 95% to40°C
Safety Features
1. The Balance Weights Holder may be removed for servicing. It is secured to the machine body through screws so that only
voluntarily it may be removed. Removal of this protection is therefore restricted to Authorized Service Engineers.
2. The Control Panel may be removed for servicing. It is secured to the machine body through screws so that only voluntarily it may
be removed. Removal of this protection is therefore restricted to Authorized Service Engineers.
I WARNING FASEP 2000 srl shall not be responsible for any inconvenience, breakdown, accidents caused directly
or indirectly by unauthorized service. Service to any parts by unauthorized engineers will void warranty
and will any right of the owner of the unit.
G NOTE As this unit runs at a speed below 100rpm, a safety cover is not required. However a safety cover is
recommended when balancing wheels with diameter bigger then 20".
! CAUTION The safety cover is anyway required when using the motorcycle adapter.
